ACA6 HIGH ACCURACY DIGITAL TYPE MODBUS TILT SENSOR WITH FULL TEMP-COMPENSATION

Name: ACA6 HIGH ACCURACY DIGITAL TYPE MODBUS TILT SENSOR WITH FULL TEMPCOMPENSATION
Brand: Rion
Price: 680.00 USD

Quality ACA6 HIGH ACCURACY DIGITAL TYPE MODBUS TILT SENSOR WITH FULL TEMP-COMPENSATION for sale

Brand Name : Rion

Model Number : ACA6-MB

Certification : CE, ISO

Place of Origin : Guangdong, China

MOQ : 1

Price : $680.00/Pieces >=1 Pieces

Payment Terms : T/T,Paypal

Supply Ability : 3000 Piece/Pieces per Month

Delivery Time : 7 days for samples

Packaging Details : 1pcs/box with sponge inside, 100pcs/ctn

Resolution : 0.001°

Measure axis : X/XY

Measure accuracy : 0.003~0.3°(RMS)

Response frequency : 20Hz

Communication protocol : RION 68 protocol / MODBUS protocol

Output signal : RS232 / RS485 / RS422 / TTL

Output rate : 5Hz / 15Hz / 35Hz / 50Hz can be setting

Power supply : 9~36v

Contact Now

ACA6 HIGH ACCURACY DIGITAL TYPE MODBUS TILT SENSOR WITH FULL TEMP-COMPENSATION

Optimized English Introduction:

ACA616T/ACA626T is a high-precision, full-temperature-compensated single/dual-axis tilt sensor with MODBUS digital output, developed by RION Technology based on an advanced precision tilt platform. Featuring excellent temperature stability, it operates reliably in wide temperature ranges from -40℃ to 85℃, making it ideal for long-term outdoor equipment monitoring and leveling.

Key Features:

Built-in high-precision 24-bit differential A/D converter;
Fifth-order filtering algorithm ensures precise measurement of tilt and pitch angles relative to horizontal;
Available with RS485, RS232, or TTL output interfaces for flexible system integration;
Non-contact installation design—simply mount the sensor on the object's surface with screws, no alignment required;
Strong resistance to electromagnetic interference, shock, and vibration;
Offers a significant competitive edge among domestic peers, tailored for high-end industrial applications.

▶ MAIN FEATURES

★ Single / dual axis inclination measurement ★ Wide voltage input: 9~36V

★ Measure Range :±90° optional ★ IP67 protection grade

★ Wide temperature working: -40~+85℃ ★ Resolution: 0.001°

★ Highly anti-vibration performance >2000g ★ Water-proof air-plug

★ Output mode RS232/RS485/RS422/TTL are optional ★ Size: 92×48×36mm

▶ APPLICATION FIELD

★ Engineering vehicles automatic leveling ★ Bridge & dam detection

★ Laser equipment position ★ Medical facilities angle control

★ Underground drill posture navigation ★ Precise machine tool level control

★ Geological equipment inclined monitoring

★ Railway gauging rule , gauge equipment leveling

▶ SPECIFICATIONS

ACA616T/ACA626T	Conditions	Parameters				Unit
Measure range		±10	±30	±60	±90	°
Measure axis		X/XY	X/XY	X/XY	X/XY	AXIS
Resolution		0.001	0.001	0.001	0.001	°
Measure accuracy	@25℃	0.003	0.01	0.02	0.03	°(RMS)
Zero Temp. coefficient	-40~+85℃	±0.0004	±0.0004	±0.0004	±0.0004	°/℃
Sensitivity temp-coeffi	-40~+85℃	≤50	≤50	≤50	≤100	ppm/℃
Power on time		0.5	0.5	0.5	0.5	S
Response frequency	20Hz
Output rate	5Hz / 15Hz / 35Hz / 50Hz can be setting
output signal	RS232 / RS485 / RS422 / TTL
Communication protocol	RION 68 protocol / MODBUS protocol
EMC	According to EN61000 and GBT17626
MTBF	≥98000 hours/times
Insulation Resistance	≥100MΩ
Shockproof	100g@11ms / 3 Axial Direction (Half Sinusoid)
Anti-vibration	10grms / 10~1000Hz
Protection grade	IP67
Cables	Standard 2m long, wear-resistant, wide temperature, shielded cable 5p * 5.7 mm aviation connector
Weight	≤220g(without cable)

▶ WORKING PRINCIPLE

Adopt imported core control unit and apply the principle of capacitive micro-pendulum. Using the principle of earth's gravity, when the tilting unit tilts, the earth's gravity will produce a gravitational component on the corresponding pendulum, and the corresponding electric capacity will change. By amplifying and filtering the electric capacity, the inclination is obtained after conversion.
