WCA 300M Single-Axis Inclination Module Output MEMS Tilt Sensor

MOQ : 1

Delivery Time : 2 work days

Output Interface : 3.3V TTL

Packaging Details : carton packing

Model Number : WCA300M

Resolution : 0.1°

Payment Terms : T/T,paypal

operating hours : 50000 hours / time (no failure)

Price : $7.5/Pieces

Output load : ＞500 ohm

Supply Ability : 3000/month

Anti-vibration : 10grms、10~1000Hz

Place of Origin : China

Operating temperature : -40℃~85℃

Certification : CE FCC ROHS

Measure Accuracy(RMS) : ±0.2°

Brand Name : RION

Range : 0~360°

Contact Now

WCA300M SINGLE AXIS TILT SENSOR MODULE.pdf
PRODUCT INTRODUCTION

WCA300M single-axis inclination module is a new low-cost inclination module independently developed. It adopts the latest anti-jamming platform design and integrates a new micro-mechanical sensing unit. It has wide temperature working performance, superior anti-vibration performance,stable and reliable long-term work, and effective work. The life span is up to 10 years. Each module goes through the factory'sstrict calibration procedure, which effectively eliminates the zero-bias error. Cross axial error, linearity error. Using tape packaging, it can be directly used for automatic placement with SMT placement machine, which is more efficient and lower-cost.

MAIN FEATURES
  • Resolution: 0.1°
  • Wide Measuring Range
  • Output Interface: TTL
  • Operating Voltage: DC 3.3-7V
  • Excellent Full-Temperature Performance
  • High Vibration Resistance: >100g
  • Operating Temperature Range: -40°C ~ +85°C
APPLICATIONS
  • Solar Photovoltaic Tracking Systems
  • Wind Deviation Monitoring
  • Hospital bed
  • Construction Tower Cranes
  • Vertical monitoring
  • Wind deviation monitoring
  • Building tower crane
  •  Wood working machinery
SPECIFICATION PARAMETERS
WCA300M CONDITION PARAMETER UNIT
Range SINGLEAXIS 0~360 °
Resolution
0.1 °
Measure Accuracy(RMS) 25° ±0.2 °
Temp. Drift Characteristics -40℃~85℃ ±0.2 °/℃
Response Time NO FILTERING 0.1 S
Zero deviation
±0.1 °
Static operating current DC 5V 10 mA
Power on time 1s
Operating Voltage DC 5V(Recommended value)
Operating temperature -40~85℃
Output Interface 3.3V TTL
Output load ＞500 ohm
operating hours 50000 hours / time (no failure)
Anti-vibration 10grms,10~1000Hz
Impact resistance 100g @ 11ms, 3 Axial Direction (Half Sinusoid)
Weight 30g
WCA 300M Single-Axis Inclination Module Output MEMS Tilt Sensor WCA 300M Single-Axis Inclination Module Output MEMS Tilt Sensor WCA 300M Single-Axis Inclination Module Output MEMS Tilt Sensor
